4kw to 12kw High Efficiency Enclosed Fiber Laser Cutting Machine Cutter for Thick Metal

Basic Info

Model NO.	VLF1530GR
Laser Classification	Fiber Laser Source
Laser Technology	Laser Fusion Cutting
Model No.	Vlf1530gr
Working Area	1500*3000mm
Laser Source Brand	Raycus/Ipg
Laser Cutting Head	Raytool
Servo Motor and Driver	Japanese Yaskawa Servo Motor and Driver
Transmission	Double Driver Rack Gear
Laser Source Power	1000W/1500W/2000W/3000W/4000W/6000W/8000W
Application Material	Metal
Control System	Cypcut2000
Repeated Positioning Accuracy	+/-0.02mm
Specified Voltage and Frequency	380V 50Hz/60Hz
Max. Acceleration	1.5g
Max. Running Speed	120m/Min
Graphic Format Supported	Ai, Plt, Dxf, BMP, Dst, Iges
Transport Package	40FT Container
Specification	8850*2850*2310mm
Trademark	VMADE
Origin	Jinan, Shandong, China
HS Code	8456110090
Production Capacity	500 Sets/Year

Product Description

4kw to 12kw High Efficiency Enclosed Fiber Laser Cutting Machine Cutter for Thick Metal
Product Description1. Safety and No Pollution*With a fully enclosed design;*The observation window adopts an European CE Standard laser protective glass;*The smoke produced by cutting can be filtrated inside, it's non-polluting and environmentally friendly;*The weight of machine is 10000kg.2. Exchanging Platform*It adopts an up and down exchange platform;*The converter is responsible for controlling the exchanging motor;*The machine is able to finish the platform exchanging within 15s.3. The Third Generation Aviation Aluminum Gantry *It is manufactured with aerospace standards and formed by 4300 tons press extrusion molding. After aging treatment, its strength can reach 6061 T6 which is the strongest strength of all gantries. *Aviation aluminum has many advantages, such as good toughness, light weight, corrosion resistance, anti-oxidation, low density, and greatly increase the processing speed.4. The Segmented Rectangular Tube Welded BedThe internal structure of the bed adopts the aircraft metal honeycomb structure, which is welded by a number of rectangular tubes. Stiffeners are arranged inside the tubes to increase the strength and tensile strength of the bed, it also increases the resistance and stability of the guide rail so as to effectively avoid the deformation of the bed.High strength, stability, tensile strength, ensuring 20 years of use without distortion;Thickness of rectangular pipe wall is 10mm and weights 4500 kg.5. Without manual operation, it can focus automatically*Without manual focusing: The software automatically adjusts the focusing lens to realize automatic perforating and cutting plates of different thickness. The speed of automatically adjusting focus lens is ten times of the manual adjusting.*Bigger adjustment range: Adjustment range -10 mm~ +10mm, precision 0.01mm, suitable for 0 ~ 20mm different types of plates.*Long service life: Collimator lens and focus lens both have water-cooling heat sink which reduces the temperature of the cutting head to improve the life of the cutting head.6. Transmission and PrecisionVMADE fiber laser cutting machine is equipped with TAIWAN APEX/YYC rack, Japanese Yaskawa motor and German Neugart reducer. The positioning accuracy of the machine tool can be 0.02mm and the cutting acceleration is 1.5G. The working life is up to 10 years.

Details



Technical Parameter

Model	VLF1530GR Fiber laser cutting machine
Working Area	1500*3000mm and 3000mm length Exchange Pallet
Laser Power	1000w/1500w/2000w/3000w or bigger
Laser Wave Length	1064nm
Minimum Line Width	± 0.02mm
Control System	Cypcut
Power Consumption	≤12KW
Auxiliary Gas	Oxygen,Nitrogen,Air
Fiber Laser Cutting Head	Raytools(AutoFocus) Laser Cutting Head
Driver System	1500W Fuji servo motor made in Japan
Transmit System	Dual Rack & Pinion type
Chain System	IGUS made in Germany
Working Table	Saw tooth
Maximum Idle Running Speed	1200mm/s
Position Accuracy	±0.05mm/m
Position Speed	20m/min
Cutting Thickness	Cutting Thickness
Position Type	Red Dot
Working Voltage	380V/50Hz
Working Life of Fiber Module	More than 100000 hours
Focus Lens	Imported
Liner Guider System	PMI made in Taiwan , (Option THK made in Japan)
Rack System	Germany Mordoli/Neugart
Warranty Time	3 years

Cutting Parameter
